Steel Structure Frame-1
• Steel Grade: Q235B/Q355B
• Surface treatment: 100% Hot dipped galvanized treatment/Painting
• Total Amount: 800 tons steel structure frame
• Design live Load: 15KN/SQM
• Height: 15meter
• FOB Qingdao: USD 900~1200/Ton
• MOQ: 500 SQM
• Factory Capacity: 1500-2000 tons/month
• Leading time: 20 ~45 days
• Packing: Steel pallet package for container delivery
Steel structure frame
1) Main Steel: S355JR, S235JR, SS400, St52, Q345B, Q235B etc.
2) Column & Beam: builtup or Hot rolled H-section
3) Connection method of steel structure: welding connection or bolt connection
4) Wall & Roof: EPS, Rockwool, PU sandwich, corrugated color trapezoid steel sheet
5) Door: manual/ automatic Rolled up door or Sliding door
6) Window: Plastic steel or Aluminum alloy window
7) Surface: Hot dip galvanized or painted
8) Crane: 5MT, 10MT, 15MT 20MT and more
◆ Brief Description
Steel structure frame is a Green economy building system, which is formed by the main structure (H-section steel for beam/column, C channel steel or Z channel steel for purlin), substructure (Round steel bar or Angle steel for bracing, Round steel tube for tie bar, Angle steel for angle brace), roof and wall system (using sandwich panel or single steel sheet), door and window system. Pre engineered steel structure building building is widely used as warehouse, workshop, hangar, shed, etc..
◆ Design capability
By using AutoCAD, PKPM, MTS, 3D3S, Tarch, Tekla Structures (Xsteel) and etc. we can design complex industrial building like office mansion, super marker, auto dealer shop, shipping mall, 5 star hotel.
◆ Our Advantages
1. We design different types and sizes building according to customer's needs, large or small, wide span: single span or multiple spans, the max span is 36m without middle column.
2. We proposal with low cost and maintenance: unit price range from USD25/m2 to USD50/m2 according to customers request.
3. The steel structure building fast construction and easy installation: time saving and labor saving, all the items are factory-made,pre-cut,pre-welded, pre-drilled,pre-painted or HDG in advance for saving cost and time.
4. Reduced construction waste, long using lifespan: up to 50 years.
5. We are using AutoCAD, PKPM, MTS, 3D3S, Tarch, Tekla Structures (Xsteel) and etc software to design different buildings according to request of Clients. We service clients from design, produce, delivery and election.
We can design factors with Max. Wind 280KM/H, Earthquake Class C and Roof Snow Load 200kg/SQM.
6. Nice appearance and , Earthquake Resistance, Sound Insulation, Heating Insulation treatment.
7. Others: environmental protection, stable structure, High quake-proof, water proof and fire proof, and energy conserving.
◆ Factory Overview
Factory Established in 2008
Company Area more than 40,000 SQM
Workshop More than 25,000 SQM
2 Sets CNC Flame Cutting Machines
5 Lines for builtup H profiles
3 Lines for C Girt or Z purlins
3 Lines for Corrugated Wall or Roof Metal Sheet
3 Lines for Sandwich Panel Sheet---Wall, Roof, EPS, Glasswool, Rockwool, XPS, etc
1 Set Shot Blasting Machine for Painting Pretreatment.
◆ Quality Control
1. QC processing:
1. Every 3 months meeting for Quality Audit to solve the weakness during processing and procedures
2. Every 6 months meeting for employee training.
3. Producing as to the International Steel Structure Standard with ISO 9001 Quality Control System
4. Each project, every 6 months, connecting with clients for feedback and complaints, then improve the quality control actions.
5. Quality inspection report for every process during production. Ensure 100% good quality products.
◆ Company Certificate of us:
◆ After Sales Service
1. Offer guide installation service.
2. One-stop shop steel structure building service
3. Free design service.
4. Expert oversea installation team service.
◆ Here are some successfully projects by us:
◆ Packaging & Shipping
◆ Our Customers
We serving the customer from UK, Poland, Luxemburg, France, Mozambique, Reunion Island, Botswana, Zimbabwe, Angola, Dubai, UAE, Russia, Singapore, Australia, New Zealand, Indonesia, Fiji, Sri Lanka, USA, Canada, Chile, Saint Lucia, Mexico, Chile etc. more than 40 countries in the past 10 years.
Q:Can you provide product catalog and quotation?
A: It is better if you can provide drawings(PDF or CAD),we will give you complete your drawings offer. or
We can design as the request from you, then proposal.
Q:what is you used drawing format?
A: PDF or DWG as AUTO CAD file
Q:What is the minimun order quantity?
A:No MOQ limited.
Q:What is your packing?
A:Standard export package for container transportation by sea and can be packed as customer's requested.
Q:How long is the delivery time?
A:According to project situation, usually within 30 days after receiving deposit.
Q: Do you offer guide installation service?
A: yes, we can. we can send engineer to your project site for guide installation or arrange the installation team to help erecting the building if necessary. .
Q: are you factory or trading company?
A: We are manufacture factory. And you are welcomed to visit us at any time. The quality control flow and sales team will show you our professionalism. Also you will can get best and most competitive price after visiting us
